Camera CCTV VIGI C540

VIGI Solar System Controller

Spec：Up to 3 × 31.2Ah/3*12VDC Output Battery,

More than 500 cycles; Charging Condition: -20℃~45℃(With intelligent auxiliary heat);

Discharging Condition:  -30℃~60℃ (With intelligent auxiliary heat); 1*10/100Mbps RJ45

Function:

Load Control\Battery Overtemperature Protection\Battery level display\Generation power display\Load power display\Generation power and Load power Statistics.

VIGI 5MP Full-Color Dome Network Camera

SPEC: 5MP, 2.8mm Fixed Lens,

1/2.7” Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264,

IR/White LED, 25fps/30fps (2880x1620),

PoE/12V DC, Built-In Mic,

micro-SD Slot (up to 512GB), IP67, IK10

FEATURE: Full-Color and IR Night Vision (Up to 30 m),

Smart Detection (Human &Vehicle Classification),

People & Vehicle Analytics,

SmartVid (Smart IR, 3D DNR, BLC),

ONVIF (Profile S/T/G),

Remote Monitoring,

VIGI App, Web, NVR GUI, VMS, VIGI Config Tool

VIGI 4MP Outdoor Full-Color Bullet Network Camera

SPEC: 4MP, 2.8mm Fixed Lens, 1/3” Progressive Scan CMOS, H.265+/H.265/H.264+/H.264, IR/White LED, 25fps/30fps (2560x1440), PoE/12V DC, Built-In Mic/Speaker, micro-SD Slot (up to 512GB), IP67, Plastic and metal

FEATURE: Full-Color and IR Night Vision (Up to 30 m), Active Defense, Two-Way Audio, On-Board Storage, Smart Detection (Human &Vehicle Classification), SmartVid (Smart IR, DWDR, 3D DNR, BLC), ONVIF (Profile S/T/G), Remote Monitoring, VIGI App, Web, NVR GUI, VMS, VIGI Config Tool

VIGI 2MP Outdoor IR Bullet Network Camera

SPEC: 2MP, 4mm Fixed Lens,

1/3” Progressive Scan CMOS, H.265+/H.265/H.264+/H.264,

IR LED, 25fps/30fps (1920x1080), PoE, Built-In Mic, IP67

FEATURE: IR Night Vision (Up to 50 m),

Smart Detection (Human &Vehicle Classification),

SmartVid (Smart IR, DWDR, 3D DNR, BLC),

ONVIF (Profile S/T),

Remote Monitoring,

VIGI App, Web, NVR GUI, VMS,

VIGI Config Tool

• Ultra-Low Light Color Night Vision: Capture 24-hour 4MP high-quality and colorful video even in ultra low-light conditions without any supplemental lights.
• 360° Monitoring: Cover every corner and eliminate blind spots.
• People & Vehicle Analytics*: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency.*
• Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
• Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
• True WDR Technology^§: Enable crystal-clear images in high contrast scenes.
• Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
• Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere.
• H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
• IP66 Waterproof: Reliable IP66 for stable outdoor performance.

VIGI 8MP Full-Color Turret Network Camera

SPEC: 8MP, 2.8mm Fixed Lens, 1/2.7” Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264, IR/White LED, 25fps (3840 × 2160),

IP67, PoE/DC 12V,120dB WDR, Built-in Mic/Speaker, micro-SD Slot (up to 512GB)

FEATURE: Full-Color and IR Night Vision (Up to 30 m),

Smart Detection (Human &Vehicle Classification),

People & Vehicle Analytics, SmartVid (Smart IR, 3D DNR, BLC),

ONVIF (Profile S/T/G),

Remote Monitoring, VIGI App, Web, NVR, VMS, VIGI Config Tool

• Ultra-Low Light Color Night Vision: Capture 24-hour 4MP high-quality and colorful video even in ultra low-light conditions without any supplemental lights.
• People & Vehicle Analytics: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency^§.
• Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
• Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
• True WDR^‡: Enable crystal-clear images in high contrast scenes.
• Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
• Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere.
• H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
• IP67 Waterproof: Reliable IP67 for stable outdoor performance.
• Flexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot^† (up to 256GB).

VIGI 5MP Full-Color Turret Network Camera

SPEC: 5MP, 2.8mm Fixed Lens, 1/2.7” Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264, IR/White LED, 25fps/30fps (2880 × 1620),

IP67, PoE/DC 12V,120dB WDR, Built-in Mic/Speaker, micro-SD Slot (up to 512GB)

FEATURE: Full-Color and IR Night Vision (Up to 30 m),

Smart Detection (Human &Vehicle Classification),

People & Vehicle Analytics, SmartVid (Smart IR, 3D DNR, BLC),

ONVIF (Profile S/T/G), Remote Monitoring, VIGI App, Web, NVR, VMS, VIGI Config Tool

VIGI 8MP Outdoor IR Panoramic Bullet Network Camera

SPEC: 8MP, 1.65mm Fixed Lens, 1/2.7’’ Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264, IR LED,

25fps/30fps (3840 × 2160),

IP67, IK10, PoE/DC 12V,120dB WDR,

Built-in Mic/Speaker, micro-SD Slot (up to 512GB),

Alarm In/Out, Audio In/Out

FEATURE: 180° Panorama View, Red-Blue Warning, Lights IR Night Vision (Up to 20 m),

Smart Detection (Human &Vehicle Classification), People & Vehicle Analytics,

SmartVid (Smart IR, 3D DNR, BLC), ONVIF (Profile S/T/G),

Remote Monitoring, VIGI App, Web, NVR, VMS, VIGI Config Tool

VIGI Intelligent Power Supply System Without Solar Panel

Spec：31.2Ah/3*12VDC Output Battery,

More than 500 cycles; Charging Condition: -20℃~45℃(With intelligent auxiliary heat);

Discharging Condition:  -30℃~60℃ (With intelligent auxiliary heat); 1*10/100Mbps RJ45

Function:

Load Control\Battery Overtemperature Protection\Battery level display\

Generation power display\Load power display\Generation power and Load power Statistics.

VIGI 5MP Outdoor Full-Color Bullet Network Camera

SPEC: 5MP, 6mm Fixed Lens, 1/2.7” Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264, IR/White LED, 25fps/30fps (2880 × 1620),

IP67, PoE/DC 12V,120dB WDR, Built-in Mic/Speaker, micro-SD Slot (up to 512GB)

FEATURE: Full-Color and IR Night Vision (Up to 30 m),

Smart Detection (Human &Vehicle Classification), People & Vehicle Analytics,

SmartVid (Smart IR, 3D DNR, BLC), ONVIF (Profile S/T/G), Remote Monitoring,

VIGI App, Web, NVR, VMS, VIGI Config Tool

VIGI 4MP IR Dome Network Camera

SPEC: 4MP, 2.8mm Fixed Lens,

1/3” Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264, IR LED,

25fps/30fps (2560x1440), PoE/DC 12V, Built-In Mic, IP67, IK10

FEATURE: IR Night Vision (Up to 30 m),

Smart Detection (Human &Vehicle Classification),

SmartVid (Smart IR, DWDR, 3D DNR, BLC),

ONVIF (Profile S/T), Remote Monitoring,

VIGI App, Web, NVR GUI, VMS, VIGI Config Tool

• 4MP Super-High Definition and IR Night Vision
• Human & Vehicle Classification
• Smart Detection
• Smart Video Enhancement Technology
• Built-In Microphone
• H.265+ Compression Technology
• Corridor Mode

VIGI 4MP Full-Color Turret Network Camera

SPEC: 4MP, 4mm Fixed Lens, 1/2.7” Progressive Scan CMOS,

H.265+/H.265/H.264+/H.264, IR/White LED, 25fps/30fps (2688 × 1520),

IP67, PoE/DC 12V,120dB WDR, Built-in Mic/Speaker, micro-SD Slot (up to 512GB)

FEATURE: Full-Color and IR Night Vision (Up to 30 m),

Smart Detection (Human &Vehicle Classification),

People & Vehicle Analytics, SmartVid (Smart IR, 3D DNR, BLC),

ONVIF (Profile S/T/G),

Remote Monitoring,

VIGI App, Web, NVR, VMS, VIGI Config Tool

VIGI 4MP Outdoor Full-Color 4G Bullet Network Camera

SPEC: 4G Cat4, LTE-TDD/LTE-FDD/WCDMA, 3*LAN Ports, 4MP,

1/2.7” Progressive Scan CMOS, H.265+/H.265 /H.264+/H.264,

IR&White LED, 25fps/30fps (2688 × 1520), IP66, DC 12V,120dB WDR,

Built-in Mic/Speaker, micro-SD Slot (up to 512GB)

FEATURE: 4G Mobile Networking, 3 LAN Ports for Downstream Devices,

Full-Color and IR Night Vision (Up to 30 m), Smart Detection(Human &Vehicle Classification),

SmartVid (Smart IR, 3D DNR, BLC), ONVIF (Profile S/T/G), Remote Monitoring,

VIGI App, Web, NVR GUI, VMS, VIGI Config Tool

8MP Full-Color Bullet Network Camera

SPEC: 8MP, 2.8mm Fixed Lens, 1/2.7” Progressive Scan CMOS, H.265+/H.265/H.264+/H.264, IR/White LED, 25fps(3840 × 2160), IP67,Web, PoE/DC 12V,120dB WDR, Built-in MIC/Speake, micro-SD Slot

FEATURE: Full-Color and IR Night Vision (Up to 30 m), Smart Detection (Human &Vehicle Classification)(MotionDetection, Area lntrusion Detection, Line-Crossing Detection, Camera Tampering Detection, Abandoned ObiectDetection, Obiect Removal Detection, Area Entrance Detection, Area Exiting Detection, Human Detection), SmartVid (Smart IR, 3D DNR, BLC), ONMF, Remote Monitoring, VIGI App, Web, VIGI Security Manager
